| Product Parameters | Value |
|---|---|
| Bucket Capacity | 0.03m³ |
| Operating Weight | 1700kg |
| Engine Model | Gasoline |
| Rated Output Power | 24hp |
| Maximum Torque/Rotational Speeds | 141N.m,1800rpm |
| Maximum Walking Speed (High/Low) | 3.4/1.9km/h |
| Slewing Speed | 10.5rpm |
| Maximum Climbing Ability | 30° |
| Bucket Digging Force | 13.5kN |
| Digging Force of Stick | 10.1kN |
| Theoretical Maximum Traction | 17.5kN |
| Hydraulic Tank Capacity | 15.3L |
| Fuel Tank Capacity | 15.3L |
| Total Width | 990/1240mm |
| Total Height(With Roll Cage) | 2350mm |
| Total Length | 3400mm |
| Maximum Digging Depth | 1800mm |
| Maximum Digging Height | 2400mm |
| Maximum Unloading Height | 2000mm |
| Ground Pressure | 32.8kpa |
