| Product Parameters | Value |
|---|---|
| Height Max Working | 2100mm |
| Max Pin Height | 1880mm |
| Max Dumping Distance | 1480mm |
| Max Dumping Height | 430mm |
| Max Dumping Angle | 30° |
| Rollback of Bcuket on Ground | 25° |
| Departure Angle | 16° |
| Total Height | 1270mm |
| Ground Clearance | 110mm |
| Gradeability | 30° |
| Total Width | 1155mm |
| Bucket Width | 1150mm |
| Total Length with Bucke | 2285mm |
| Turn Radius Forward Turning | 1300mm |
| Rated Power | 23hp |
| Rotating Speed | 3600rpm |
| Fuel Tank | 25L |
| Pressure | 17Mpa |
| Hydraulic Tank | 25L |
| Rated Load Capacity | 200kg |
| Bucket Capacity | 0.15m³ |
| Max Lifting Force | 375kg |
| Travel Speed | 0-6km/h |
| Working Weight | 890kg |
