| Product Parameters | Value |
|---|---|
| Engine Brand | Koop/Runtong/B&S |
| Rated Power | 7.5/8.6/9.9kW |
| Number of Cylinders | 1 |
| Air Intake Way | Naturally Aspirated |
| Emissions Standards | Euro5/EPA |
| Rated Operating Capacity | 200kg |
| Maximum Operating Capacity | 300kg |
| Maximum Breakout Force | 3.5kN |
| Bucket Capacity | 0.12m³ |
| Driving Speed | 0-6km/h |
| Total Cycling Time | 9s |
| System Operating Pressure | 17bar |
| Operating Weight | 1050kg |
| Fuel Tank Capcity | 5L |
| Vehicle Height | 1250mm |
| Length with Standard Bucket | 2400mm |
| Vehicle Width (Standard Tire) | 960mm |
| Length Without Standard Bucket | 1900mm |
| Bucket Width | 1050mm |
| Tail Length | 200mm |
| Height at Maximum Extension | 2620mm |
| Height to the Bucket Pin | 2000mm |
| Maximum Height as Lay the Bucket Flat | 1830mm |
| Dumping Height | 1470mm |
| Discharge Distance | 600mm |
| wheelbase | 800mm |
| Ground Clearance | 180mm |
| The Flip Angle of the Bucket on the Ground | 27° |
