| Product Parameters | Value |
|---|---|
| Engine Brand | Koop/Runtong/B&S |
| Rated Power | 15/19.2/17kW |
| Number of Cylinders | 2 |
| Air Intake Way | Naturally Aspirated |
| Emissions Standards | Euro5/EPA |
| Rated Operating Capacity | 300kg |
| Maximum Operating Capacity | 400kg |
| Maximum Breakout Force | 4.5kN |
| Bucket Capacity | 0.12m³ |
| Driving Speed | 0-6km/h |
| Total cycling time | 9s |
| System Operating Pressure | 17-21bar |
| Operating Weight | 1200kg |
| Fuel Tank Capcity | 10L |
| Vehicle Height | 1300mm |
| Length with Standard Bucket | 2140mm |
| Vehicle Width (Standard Tire) | 1050mm |
| Length Without Standard Bucket | 1850mm |
| Bucket Width | 1050mm |
| Tail Length | 500mm |
| Height at Maximum Extension | 2400mm |
| Height to the Bucket Pin | 1870mm |
| Maximum Height as Lay the Bucket Flat | 1720mm |
| Dumping Height | 1510mm |
| Discharge Distance | 250mm |
| Wheelbase | 800mm |
| Ground Clearance | 110mm |
| The Flip Angle of the Bucket on the Ground | 27° |
