| Product Parameters | Value |
|---|---|
| Operating Weight | 750kg |
| Static Line Load | 60N/cm |
| Working Speed | 0-4.5km/h |
| Climbing Ability | 30° |
| Minimum Mturning Radius | 1500mm |
| Hydraulic Oil Tank Capacity | 9L |
| Fuel Tank Capacity | 5L |
| Water Tank Capacity | 38.8L |
| Vibration Frequency | 61Hz |
| Amplitude | 0.65mm |
| Exciting Force | 14kN |
| Steel Wheel Diameter | 530mm |
| Working Width | 700mm |
| Engine Model | CF180FE-4 |
| Engine Fuel Type | Diesel |
| Engine Rated Power | 4.4kw (6hp) |
| Engine Rated Speed | 3600r/min |
| Wheelbase | 1100mm |
