| Product Parameters | Value |
|---|---|
| Operating Weight | 642kg |
| Cargo Box Capacity | 0.145m³ |
| Climbing Ability | 20° |
| Maximum Load | 200kg |
| Travel Speed | 0.8-1.7km/h |
| Minimum Turning Radius | 1420mm |
| Track Center Distance | 825mm |
| Minimum Ground Clearance | 85mm |
| Track Contact Length | 825mm |
| Cargo Box Tilting Angle | 90° |
| Mixing Drum Diameter | 600mm |
| Feed Inlet Diameter | 423mm |
| Mixing Drum Depth | 612mm |
| Bucket Lifting Height | 1622mm |
| Bucket Lifting Length | 1767mm |
| Unloading Height from Ground | 232mm |
| Overall Dimensions | 2155*800*1228mm |
| Engine Model | Koop/Rato/B&S |
| Rated Power | 4.2/4.8/4.78kW |
| Cylinder | 1 |
| Intake Method | Naturally Aspirated |
| Emission Standard | EPA/Euro5 |
| Fuel Tank Capacity | 3.1L |
